| 參數(shù) | Specifications | 技術指標 Technique data | |||
| 線性行程 | Stroke length | 0~30°…120°…350°或0~…0~±15°…±60°…±175°（每10°遞增） | |||
| 工作電壓 | Operatingvoltage | 24VDC（12~32VDC) | |||
| 重復性 | Repeatability | 0.01° | |||
| 輸出信號 | Outputsignal | 4~20mA，0~5V，0~10V，0~±5V，0~±10V | |||
| 綜合精度 | Non-linearity | ±0.25%F.S，±0.5%F.S，±1%F.S | |||
| 通道一致性誤差 | Channel consistency | ≯0.5% FS | |||
| 工作溫度 | Operating temperature | -40~85℃ | |||
| 抗振性能 | Vibration proof | 20g(5…2000Hz) | |||
| 溫度系數(shù) | Temperaturecoefficient | ±0.05%F.S/℃ | |||
| 轉動速度 | Operatingspeed | 1.5°/s | |||
| 外殼材質 | Material | 不銹鋼 Stainless steel | |||
| 防護等級 | Ip protection | IP54 | |||
