NS-E
應用于石化、環保、水利等領域
通過EMC、鹽霧、溫濕度測試
投入式
全不銹鋼封裝
防水通氣電纜與外殼密封連接
可為用戶提供配套的水深測壓儀
| 參數 | Specifications | 技術指標 Technique data | |||||||||
| 測量范圍 | Measuring ranges | 0~0.5m…1m…10m…30m…50m…100m…150m…200mH2O | |||||||||
| 過載壓力 | Overload pressures | 200%F.S | |||||||||
| 破壞壓力 | Burst pressures | 500%F.S | |||||||||
| 工作方式 | Operational Mode | 表壓 | |||||||||
| 測量介質 | Measuring Media | 水、油 | |||||||||
| 輸出信號 | Output signal | 4~20mA 0~5VDC 0~10VDC | |||||||||
| 工作電壓 | Operating voltage | 24VDC(12~32VDc) | |||||||||
| 綜合精度 | Accuracy | ±0.1%F.S ±0.25%F.S | |||||||||
| 長期穩定性 | Long-term drift | ≤±0.15%F.S/ year（typ.） | |||||||||
| 溫度補償范圍 | Compensated temperature range | -20~+80℃ | |||||||||
| 工作溫度范圍 | Operating temperature range | -30~+80℃ | |||||||||
| 儲存溫度范圍 | Storage temperature range | -40~+120℃ | |||||||||
| 流體溫度范圍 | Fluid temperature range | -30~+120℃ | |||||||||
| 絕緣阻抗 | Insulation resistance | ≥100MΩ(100VDC) | |||||||||
| 耐振性能 | Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| 耐沖擊性 | Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| 抗干擾 | EMC proof | IEC 61000-6-2/3/4 | |||||||||
| 外殼材質 | Material | 不銹鋼 | |||||||||
| 防護等級 | Ip protection | IP68 | |||||||||
