| 參數 | Specifications | 技術指標 Technique data | |||||||||
| 測量范圍 | Measuring ranges | 0.75mH2O~600mH2O | |||||||||
| 過載壓力 | Overload pressures | 150%F.S | |||||||||
| 破壞壓力 | Burst pressures | 350%F.S | |||||||||
| 工作方式 | Operational Mode | 表壓、絕壓 | |||||||||
| 測量介質 | Measuring Media | 水、油 | |||||||||
| 輸出信號 | Output signal | 25、50、100mV | |||||||||
| 工作電壓 | Operating voltage | mV輸出：10VDC(2.5~12VDc) mA輸出：9~30VDc | |||||||||
| 綜合精度 | Accuracy | ±0.1%F.S | |||||||||
| 長期穩定性 | Long-term drift | ≤±0.1%F.S/ year（typ.） | |||||||||
| 溫度補償范圍 | Compensated temperature range | -2~+30℃ | |||||||||
| 工作溫度范圍 | Operating temperature range | -20~+60℃ | |||||||||
| 輸出阻抗 | Output impedance | 2KΩ | |||||||||
| 絕緣阻抗 | Insulation resistance | ≥100MΩ(500VDC) | |||||||||
| 耐振性能 | Vibration resistance | IEC 60068-2-6 (5…2000Hz, 20g) | |||||||||
| 耐沖擊性 | Shock resistance | IEC 60068-2-27 (50g, 11ms) | |||||||||
| 抗干擾 | EMC proof | IEC 61000-6-2/3/4 | |||||||||
| 外殼材質 | Material | 鈦 | |||||||||
| 防護等級 | Ip protection | IP68 | |||||||||
